Faital Pro 15HP1060 8ohm 15″ 1000 watt Neo Subwoofer

Faital Pro 15HP1060 8ohm 15″ 1000 watt Neo Subwoofer

15HP1060 specifications:

• Nominal Impedance: 8 Ohm
• Minimum Impedance: 6.4 Ohm
• AES Power Handling: 1000 W
• Maximum Power Handling: 2000 W
• Sensitivity (1W/1m): 97 dB
• Frequency Range: 40÷2000 Hz
• Voice Coil Diameter: 100 mm (4 in)
• Winding Material: Cu
• Former Material: Glass Fiber
• Winding Depth: 28.9 mm (1.14 in)
• Magnetic Gap Depth: 12 mm (0.47 in)
• Flux Density: 1.22 T
• Magnet: Neodymium Ring
• Basket Material: Aluminum
• Demodulation: Aluminum Ring
• Cone Surround: Triple Roll
• NET Air Volume filled by Loudspeaker: 4.1 dm^3 (0.145 ft^3)
• Spider Profile: 2x non-adjacent symmetrical variable height waves

Thiele and small parameters:

• Fs: 40 Hz
• Re: 5 Ohm
• Qes: 0.32
• Qms: 11.4
• Qts: 0.31
• Vas: 100.3 dm^3 (3.54 ft^3)
• Sd: 842 cm^2 (130.51 in^2)
• Xmax: 12.45 mm
• Xdamage: 21 mm
• Mms: 156.3 g
• Bl: 24.8 N/A
• Le: 1.32 mH
• Mmd: 128.7 g
• Cms: 0.10 mm/N
• Rms: 3.4 kg/s
• Eta Zero: 1.95 %
• EBP: 125 Hz

Nominal parameters:
