Eighteen Sound NSD1480N 16 Ohm 1.4″ 100W Compression Driver

Eighteen Sound NSD1480N 16 Ohm 1.4″ 100W Compression Driver

Key features:

• 111 dB 1W / 1m average sensitivity
• 1,4 inch exit throat 3 inch voice coil diameter
• 200W program power handling
• Titanium Nitride Coated Dome
• True Piston Motion TiN coated titanium diaphragm
• High grade neodymium magnetic structure
• Excellent thermal exchange

NSD1480N specifications:

• Throat Diameter: 35 mm (1.4 in)
• Nominal Impedance; 16 Ω
• Minimum Impedance: 12.9 Ω
• Nominal Power Handling: 100 W
• Continuous Power Handling: 200 W
• Sensitivity: 111.0 dB
• Frequency Range: 0.5 – 20.0 kHz
• Recommended Crossover: 0.8 kHz
• Voice Coil Diameter: 75 mm (3.0 in)
• Flux Density; 2.2 T

Mounting and Shipping Info:

• Overall Diameter: 131 mm (5.16 in)
• Depth: 62 mm (2.44 in)
• Net Weight: 3.1 kg (6.83 lb)
• Shipping Weight: 3.3 kg (7.28 lb)
• Shipping Box: 132x132x68 mm (5.20×5.20×2.6 8 in)
