Eighteen Sound ND2080 16 Ohm 2″ 100W Compression Driver
Product description:
The ND2080 2-inch exit high frequency compression driver has been designed for high quality sound systems application.
The titanium diaphragm is produced in house & has been developed to assure unmatched transient response.
The diaphragm assembly is made by joining the former directly to the titanium dome on its upper bend edge.
In comparison w/ a usual straight former joint, the driver design assures extended frequency energy transfer for improved response linearity & unparallel reliability.
Key features:
- 110 dB SPL 1W / 1m average sensitivity
- 2 inch exit throat
- 3 inch edgewound aluminum voice coil
- 200 W program power handling
- Pure Titanium diaphragm assembly
- Neodymium ring magnetic structure
- Excellent thermal exchange
Product specifications:
- Throat Diameter: 50 mm (2 in)
- Rated Impedance: 16 ohm
- DC Resistance: 12.4 ohm
- Minimum Impedance: 16 ohm at 3500 Hz
- Le (at 1kHz): 124 µH
- AES power: 100 W above 1,2 kHz
- Program power: 200 W above 1,2 kHz
- Sensitivity: (@ 1W/1m) 110 dB
- Frequency Range: 500 Hz ÷ 20 kHz
- Recomm. Xover Frequency: 800Hz 12 dB/octave
- Diaphragm Material: Titanium
- Voice Coil Diameter: 75 mm (3 in)
- Voice Coil: Winding Material Edge-wound aluminum
- Magnet Material Neodymium
- Flux Density: 2,2 T
- BL Factor: 15,5 N/A
- Polarity Positive voltage on red terminal gives positive pressure in the throat
Designed & manufactured in Italy and provided exclusively by Lean Business, this Eighteen Sound speaker comes complete with 2 years warranty.
