RAM AUDIO PI4-10K, 10000 Watt, 4 channel Amplifier with DSP 4 x 2500W, 4 ohm

RAM AUDIO PI4-10K, 10000 Watt, 4 channel Amplifier with DSP 4 x 2500W, 4 ohm

Key features:

• Extra-large 4.3″ IPS display, capacitive touch panel user interface
• 64 bits double-precision 96kHz DSP process, and high performance 96kHz/24 bits AD/DA converters.
• Available versions with Dante™ Networking (AES67 and DDM compatible) and AES3 Digital inputs
• Two ports Ethernet switch for daisy chain connection
• USB port for firmware update and DSP control
• High voltage output for high headroom performances
• QuantaPulse™ SMPS
• Similar power per channel in any impedance
• RAM Audio advanced Power Management System to squeeze until the last watt for your speakers
• Exceptional power sharing in asymmetrical loads
• Powerful and fast response cooling system
• Industry standard Neutrik® XLR and Speakon® connectors

 PI4-10K  specifications:

• Number of channels: 4
• Total output power: 10000W
• Output power @ 2 Ohm (all channels driven): 4 x 2500W
• Output power @ 2 Ohm (single channel): 1 x 2500W
• Output power @ 4 Ohm (all channels driven): 4 x 2500W
• Output power @ 4 Ohm (single channel): 1 x 3000W
• Output power @ 8 Ohm (all channels driven): 4 x 1600W
• Output power @ 8 Ohm (single channel): 1 x 1800W
• output power @ 4 Ohm (bridge mode): 2 x 5000W
• Output power @ 8 Ohm (bridge mode): 2 x 5000W
• High Z 70Vrms / 100Vpeak: 4 x 2500W
• High Z 100Vrms / 140Vpeak: 4 x 2500W
• Output voltage max: 176 Vpeak
• Output current max: 50 Apeak
• Total harmonic distortion (THD): <0.05%.
• Intermodulation distortion (SMPTE): <0.05%
• Voltage gain: 26dB – 44dB (1dB step)
• Signal to noise ratio: 107.5 dB
• Operating voltage: 170 V AC – 255 V AC, 50 – 60 Hz, 90 V AC – 140 V AC, 50 – 60 Hz
• 1/8 Rated power (@230V/4 ohms): 16 A
• Protection circuits: Power on/off transients, ICL™, short circuit, open or unequal loads, PMS™, RF, soft start, SSP™, power on mute, overheat, power supply overload.
• Dimensions (WxDxH): 483 x 320 x 89 mm
