Eighteen Sound ND1090 16 Ohm 1″ 50W Compression Driver

Eighteen Sound ND1090 16 Ohm 1″ 50W Compression Driver

Key features:

• 1 inch exit throat
• 109 dB 1W / 1m average sensitivity
• 44 mm (1 3/4 inch) edgewound aluminum voice coil
• PEN diaphragm for extended frequency response
• Proprietary phase plug design
• Neodymium ring magnet for excellent transient response
• Excellent thermal exchange

ND1090 specifications:

• Throat Diameter: 25 mm (1.0 in)
• Nominal Impedance: 16 Ω
• Minimum Impedance: 11.9 Ω
• Nominal Power Handling: 50 W
• Continuous Power Handling: 100 W
• Sensitivity: 110.0 dB
• Frequency Range: 1.6 – 20.0 kHz
• Recommended Crossover: 1.6 kHz
• Voice Coil Diameter: 44 mm (1.75 in)
• Flux Density: 2.0 T

Mounting and Shipping Info:

• Overall Diameter: 93 mm (3.66 in)
• Depth: 53 mm (2.09 in)
• Net Weight: 1.1 kg (2.43 lb)
• Shipping Weight: 1.2 kg (2.65 lb)
• Shipping Box: 97x97x58 mm (3.82×3.82×2.2 8 in)
