Faital Pro HF146 16ohm 1.4″ 70 watt Neo Compression Driver

Faital Pro HF146 16ohm 1.4″ 70 watt Neo Compression Driver

HF146 specifications:

• Throat Diameter: 35.6 Inches (1.4 in)
• Overall Diameter: 123 mm (4.84 in)
• Overall Depth: 63.5 mm (2.50 in)
• Impedance: 16 ohm
• Minimum Impedance: 14.4 ohm
• Sensitivity: 109 dB
• Frequency Range: 0.7:18 Hz
• Voice Coil Diameter: 65 mm (2.56 in)
• Voice Coil Material: Al
• Voice Coil Former: Kapton
• Voice Coil Depth: 3.75 mm (0.15 in)
• Magnetic Gap Depth: 4.2 mm (0.17 in)
• Diaphragm Material: Ketone
• Magnet Material: Neodymium Slug Crown
• Flux Density: 1.7 T

Mounting & dimensions:

• Throat Diameter – 35.6 mm (1.4 in)
• Overall Diameter – 123 mm (4.84 in)
• 90° Mounting Holes Diameter (4xM6) – 102 mm (4.02 in)
• Depth – 63.5 mm (2.50 in)
• Net Weight – 2 Kg (4.4 lb)
• Shipping Box – 185 x 170 x 122 mm (7.3 x 6.7 x 4.8 in)
• Shipping Weight – 2.3 Kg (5.1 lb)

Designed & manufactured in Italy and provided exclusively by Lean Business, this FaitalPRO compression driver comes complete with 2 years warranty.
