SB ACOUSTICS SW26DBAC76-8 10” 8ohm Neodymium Aluminium Cone SHALLOW SUBWOOFER Loudspeaker
£252.78
- Unique patented long through shallow design
- Powerful neodymium motor system
- Vented cast aluminum cone structure
- Non conducting fiber glass coil former for minimum damping
- Shorting ring in motor system for reduced distortion
- Long life silver lead wires
A high quality product supplied by Lean Business Audio.
Visit our website for offers on 1000’s of audio products.
Worldwide shipping and Free Delivery on selected brands.
In stock (can be backordered)
SB ACOUSTICS SW26DBAC76-8 10” 8ohm Neodymium Aluminium Cone SHALLOW SUBWOOFER Loudspeaker
Product Description:
The SB Acoustics SW26DBAC76-8 Aluminum 10 inch 8 ohm shallow Subwoofer can give great low-end extension in a shallow enclosures due to its unique long trough design.
With a depth of only 70.5 mm its good for applications where clearance can become an issue.
A sealed enclosure with a volume of 40Ltr is recommend for optimal performance. This driver is not recommended for a bass-reflex/ported enclosures.
Key Features:
- Unique patented long through shallow design
- Powerful neodymium motor system
- Vented cast aluminum cone structure
- Non conducting fiber glass coil former for minimum damping
- Shorting ring in motor system for reduced distortion
- Long life silver lead wires
SW26DBAC76-8 Specifications:
- Woofer Type: Subwoofer
- Nominal Diameter: 10”
- Power Handling (RMS): 250 Watts
- Impedance (Z): 8 Ohms
- Sensitivity: 83 dB(2.83V/1m)
- Voice Coil Diameter: 75.5 mm
- Magnet Weight: 281 g
- DC Resistance (Re): 6.4 Ohms
- Resonant Frequency (Fs): 19.5 Hz
- Mechanical Q (Qms): 4.4
- Electromagnetic Q (Qes): 0.29
- Total Q (Qts): 0.28
- Diaphragm Mass Inc. Airload (Mms): 172 g
- Mechanical Compliance of Suspension (Cms): 0.39 mm/N
- Surface Area of Cone (Sd): 312 cm2
- BL Product (BL): 21.4 Tm
- Maximum Linear Excursion (Xmax): 24 mm (p-p)
- Driver’s Mechanical Losses (Rms): 4.8 kg/s
- Cone / Diaphragm Material: Aluminum
- Voice Coil Wire Material: Copper
- Voice Coil Former: Glass Fiber
- Basket / Frame Material: Aluminum
- Magnet Material: Neodynium
- Overall Outside Diameter: 290 mm
- Overall Depth: 84.6 mm
- Bolt Circle Diameter: 5.5 mm
- # Mounting Holes: 8
- Mounting Hole Diameter: 249 mm
Why Choose Lean Business Audio?
50 years of experience of designing, building and supplying Home, Car and Professional Audio.
Huge stocks of leading loudspeakers and audio brands
KEF, Celestion, Eminence, WGS, Montage, BMS Speakers, Faital Pro, Eighteen Sound, Ciare
Low Worldwide shipping rates.
Free Delivery on selected brands with the UK.
Price matching.
For more information please contact us at: +44(0)1473 744089
Or Email us at: sales@lean-business.co.uk
| Weight | 5 kg |
|---|---|
| Brand | SB ACOUSTICS |
| Size | 10'' |
| Magnet type | Neodymium |
