SB ACOUSTICS SATORI TW29DN-8 29mm 8ohm Neodymium Large Surround Dome Tweeter
£132.93
- Large surround dome for increased acoustic output
- Dual balanced compression chamber for improved dynamics
- Dual copper caps for absolute minimum voice coil inductance and minimum phase shift
- Two part aluminium faceplate with integrated mechanical decoupling
- High saturation neodymium motor system with T-shaped pole piece for lower distortion
A high quality product supplied by Lean Business Audio.
Visit our website for offers on 1000’s of audio products.
Worldwide shipping and Free Delivery on selected brands.
Only 2 left in stock
SB ACOUSTICS SATORI TW29DN-8 29mm 8ohm Neodymium Large Surround Dome Tweeter
Key Features:
- Large surround dome for increased acoustic output
- Dual balanced compression chamber for improved dynamics
- Dual copper caps for absolute minimum voice coil inductance and minimum phase shift
- Two part aluminium faceplate with integrated mechanical decoupling
- High saturation neodymium motor system with T-shaped pole piece for lower distortion
- Non-reflective cast aluminium chamber with optimized damping for improved dynamics
- Shallow flow optimized magnet structure for optimum coupling to rear chamber
- CCAW voice coil for low moving mass
- Long life silver lead wires
- Low resonance frequency for extended range
TW29DN-8 Specifications:
| SB Acoustics Description |
SATORI TW29DN-8
|
| Speaker Type |
Satori Tweeter
|
| Dome Material |
Fabric
|
| Qty |
30
|
| Shipping Box / Inner Box (cm) |
13.6*12.8*4.9
|
| Shipping Box / Outer Box (cm) |
66.1*29.1*17.4
|
| Nominal Impedance (Ω) |
8
|
| DC Resistance, Re (Ω) |
6.2
|
| Voice Coil Inductance, Le (mH) |
0.04
|
| Effective piston area, Sd (cm²) |
9.6
|
| Voice Coil Diameter (mm) |
29
|
| Voice Coil Height (mm) |
2
|
| Air Gap Height (mm) |
2.5
|
| Linear Coil Travel (p-p) (mm) |
0.5
|
| Moving Mass Incl. Air, Mms (g) |
0.43
|
| Free Air Resonance, Fs (Hz) |
650
|
| Sensitivity (2.83 V / 1 m) (dB) |
93
|
| Mechanical Q-factor, Qms |
1.61
|
| Electrical Q-factor, Qes |
0.65
|
| Total Q-factor, Qts |
0.46
|
| Force Factor, Bl ( Tm ) |
4.1
|
| Rated Power Handling* (W) |
80
|
| Magnetic Flux Density (T) |
1.5
|
| Magnet Weight (g) |
0.1
|
| Net Weight (kg) |
0.39
|
Why Choose Lean Business Audio?
50 years of experience of designing, building and supplying Home, Car and Professional Audio.
Huge stocks of leading loudspeakers and audio brands
KEF, Celestion, Eminence, WGS, Montage, BMS Speakers, Faital Pro, Eighteen Sound, Ciare
Low Worldwide shipping rates.
Free Delivery on selected brands with the UK.
Price matching.
For more information please contact us at: +44(0)1473 744089
Or Email us at: sales@lean-business.co.uk
| Weight | 1 kg |
|---|---|
| Brand | SB ACOUSTICS |
| Size | 29mm |
| Magnet type | Neodymium |
